Spec Item

Description

Color

Color

Black C

Communication

Wireless

IEEE 802.11a/b/g/n/ac

Dimensions

Dimensions

262 x 181 x 42 (LxWxH) (mm)

Environment

Humidity

10% to 95% (non-condensing)

IP Level

IP 64 compliant front panel

Operating Temperature

-10°C~50°C

Safety & EMC

CE / FCC

Storage Temperature

-20°C~60°C

I/O Interface

Audio

AMP 2W + 2W (internal speaker)

Audio Codec

ALC892

Ethernet

2 x PCIe GbE by RTL8111E controller

I/O Ports and Switches

1 x RS-232 COM port (RJ-45 connector)

1 x RS-232/422/485 COM port (DB-9 connector)(RI/5V/12V)

2 x USB 3.0

2 x USB 2.0

2 x RJ-45 for GbE LAN

1 x Power switch

1 x Audio port (line-out)

1 x Reset button

1 x AT/ATX switch

1 x 9-30V DC lockable power jack

LCD

Backlight MTBF

15000 hrs

Brightness (cd/m2)

350

Contrast Ratio

800:1

LCD Color

16.2M

Pixel Pitch (mm)

0.1695 (H)×0.1695 (V)

Resolution

1280 x 800 (16:10)

Size

10.1”

Viewing Angle (H-V)

170º / 170º

Other Features

Audio

AMP 2W + 2W (internal speaker)

Camera

2-megapixel with low light function

Microphone

digital microphone

OSD Function

Software OSD

System Cooling

Fanless

Physical Characteristics

Color

Black C

Construction Front Panel

PC + ABS Plastic

Cutout Dimensions

236 x 150 (W x H) (mm)

Dimensions (LxWxH) (mm)

262 x 181 x 42

Mounting

Panel, Wall, Stand, Arm VESA 75mm x 75mm

Net Weight

1.06 kgs

Power

Power consumption

[email protected] (Intel® J1900 CPU with 2GB 1333 MHz DDR3L memory)

Power Requirement

9 V ~ 30 V

Storage

Storage

mSATA

System

Cooling method / System Fan

Fanless

CPU

Intel® Celeron® J1900 (quad core, 2.0 GHz)

Memory Max.

8GB

On-board Memory

One 204-pin 2 GB 1333MHz single-channel, 2GB DDR3L SDRAM pre-installed

Storage

mSATA

Touch

Touch Controller

EETI EXC7200

Touch Screen

Projected capacitive type

Weight

Weight

1.06/2.58 (Net/Gross, kgs)
