Part Number

USB-4751-AE

USB-4751L-AE

General

Power Consumption

Typical: 5V @ 200 mA; Max.: 5V @ 500 mA

Typical: 5V @ 200 mA; Max.: 5V @ 500 mA

OS Support

32-bit/64-bit Windows 7/8/10, and Linux

32-bit/64-bit Windows 7/8/10, and Linux

Dimensions

132 x 80 x 32 mm (5.2" x 3.15" x 1.26")

132 x 80 x 32 mm (5.2" x 3.15" x 1.26")

Bus

USB 2.0

USB 2.0

I/O Connectors

0-pin box headers, pin assignments are fully compatible with Opto-22 I/O module racks

50-pin box headers, pin assignments are fully compatible with Opto-22 I/O module racks

Operating Temperature

0~60 (32~140°F)

0~60 (32~140°F)

Programming Language

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

Timer/Counter

Resolution

32 bits

32 bits

Channels

2

2

Max. Input Frequency

20 MHz

20 MHz

TTL DI/O

Input Channels

48 (shared)

24 (shared)

Output Channels

48 (shared)

24 (shared)
