Part Number

USB-4718-AE

General

Power Consumption

5V @ 100 mA

OS Support

32-bit/64-bit Windows 7/8/10, and Linux

Dimensions

132 x 80 x 32 mm (5.2" x 3.15" x 1.26")

Bus

USB 2.0

I/O Connectors

Onboard screw terminal

Operating Temperature

0~60 (32~140°F)

Programming Language

C#,C++,LabVIEW,VB.Net,BCB,MFC,VB6,Delphi,Java,Matlab,Qt

Analog Input

Sampling Rates(S/s)

10

Resolution(Bits)

16

Channels

8

Type

Scan

Unipolar Input (V)

J, K, T, E, R, S, B types Thermocouple. 0 ~ 2.5V, 0 ~ 1V, 0 ~500mV, 0 ~ 100mV, 0~50mV,0~15mV,0~20mA,4~20mA

Isolated Digital I/O

Input Channels

8

Input Range

0~30 VDC

Output Channels

8

Output Ranges

5~30 VDC
