Part Number |
AIMB-508HF-EAA1 |
AIMB-508HL-0AA1 |
Form Factor |
||
Form Factor |
Micro ATX |
Micro ATX |
Processor |
||
CPU |
Intel® 12th & 13th Generation Core? I processor |
Intel® 12th & 13th Generation Core? I processor |
CPU TDP |
65W / 35W |
65W / 35W |
BIOS |
AMI EFI 256Mbit |
AMI EFI 64Mbit |
Core Number |
Up to 24C |
Up to 24C |
Max Speed |
Up to 5.2GHz |
Up to 5.2GHz |
Smart Cache |
4MB/6MB/12MB/18MB/25MB/30MB |
4MB/6MB/12MB/18MB/25MB/30MB |
Chipset |
H610E |
H610E |
Memory |
||
Max. Capacity |
64 GB |
64 GB |
Technology |
Dual Channel DDR4 3200MHz UDIMM |
Dual Channel DDR4 3200MHz UDIMM |
ECC Support |
No |
No |
Socket |
2 x 288 pin DIMM |
2 x 288 pin DIMM |
Display |
||
Controller |
Intel UHD Graphics |
Intel UHD Graphics |
Graphic Engine |
DirectX 12,OpenGL 4.5,OpenCL 2.1 |
DirectX 12,OpenGL 4.5,OpenCL 2.1 |
Output |
1 x HDMI , 1 x DP++ , 1 x VGA |
1 x HDMI , 1 x DP++ , 1 x VGA |
DDI (HDMI/DVI/DisplayPort) |
HDMI: support to 4096x2160@60Hz |
HDMI: support to 4096x2160@60Hz |
DP++: support to 4096x2304@60Hz |
DP++: support to 4096x2304@60Hz |
|
LCD (TTL/LVDS/eDP) |
eDP: support to 3840 x 2160 @ 60 Hz |
eDP: support to 3840 x 2160 @ 60 Hz |
Multiple Display |
Dual/ Triple |
Dual/ Triple |
Expansion |
||
PCI Express x 16 |
1 |
1 |
PCI Express x 8 |
0 |
0 |
PCI Express x 4 |
1 |
1 |
Ethernet |
||
Controller |
Intel i219V and Intel i226V |
Intel i219V and Intel i226V |
Connector |
RJ45 |
RJ45 |
Storage |
||
RAID |
Software RAID 0, 1, 5, 10 |
Software RAID 0, 1, 5, 10 |
SATA |
4 x SATA III (Max. Data Transfer Rate600 MB/s) |
4 x SATA III (Max. Data Transfer Rate600 MB/s) |
I/O |
||
GPIO |
8-bit GPIO |
8-bit GPIO |
USB3.2 |
4 |
4 |
USB2.0 |
6 |
6 |
COM Port |
5 x RS232, 1 x RS232/ 422/ 485 |
5 x RS232, 1 x RS232/ 422/ 485 |
TPM |
TPM 2.0 |
TPM 2.0 |
Smart Fan |
Yes |
Yes |
Power |
||
Power Type |
ATX |
ATX |
Connector |
ATX24P |
ATX24P |
Environment |
||
Operational Temperature |
- 40 ~ 85° C (-40 ~185° F) |
- 40 ~ 85° C (-40 ~185° F) |
Non-Operational Temperature |
0 ~ 60° C (32 ~ 140° F) |
0 ~ 60° C (32 ~ 140° F) |
Vibration Resistance |
3.5 Grm |
3.5 Grm |
Physical |
||
Dimension (mm) |
244 x 244 mm |
244 x 244 mm |
Weight |
1.2 kg (2.65 lb) |
1.2 kg (2.65 lb) |
Operating System |
||
Microsoft Windows |
Windows 10 |
Windows 10 |
Linux |
Yes |
Yes |
SUSIAccess |
Yes |
Yes |
Certification |
||
EMC |
CE, FCC |
CE, FCC |
