處理器

CPU

Intel®C236

網絡

1*Intel I219-LM (10/100/1000M)

1*Intel I210 (10/100/1000M)

內存

2*DDR4 2133/2400MHz SO-DIMM Sockets, up to 64 GB (Un-buered and Non-ECC type)

顯示

Integrated Intel HD Graphics supports triple independent display

1*DVI-I: 1920 x 1080 @60Hz

2*DP: 3840 x 2160 @30Hz

儲存

2*SATA III (6Gbps) for 2.5” HDD/SSD

4*mSATA (Shared by Mini-PCIe Socket) (Gen3)

Supports S/W RAID 0, 1, 5 & 10

串口

4*RS-232/422/485 with Auto Flow Control Support 5V/12V, Db9

Optional Module

2* RS-232/422/485, DB9 Connector

4*RS-232/422/485, DB9 Connector

USB

8*USB 3.0 (Type-A)

擴展插槽

1*CFM Interface for CFM Modules

3*CMI Interface for CMI Modules

4*Full-size Mini-PCIe Sockets

1*SIM Socket

3*Antenna Holes

電源

Supports AT/ATX Power Type

Power Input Voltage 9~48VDC

1*3-Pin Terminal Block

Power AdapterAC/DC 24V/5A 120W or 24V/9.2A 220W (Optional)

外形尺寸

242 x 174 x 77 mm

工作溫度

7th Generation Intel CPU (Kaby Lake-S)

- 35W TDP CPU: -40°C 50°C

- 51W~65W TDP CPU: -40°C 45°C

- 73W TDP CPU: -40°C 40°C

6th Generation Intel CPU (Skylake-S)

- 35W TDP CPU: -40°C~70°C

- 51W~65W TDP CPU: -40°C 55°C

- 80W TDP CPU: -40°C 40°C

(With Extended Temperature Peripherals; Ambient with Air Flow;

According to IEC60068-2-1, IEC60068-2-2, IEC60068-2-14)

存儲溫度

‘-40~85°C

安裝方式

Wall固定支架 - 支架與螺絲

可選工作模組

LAN

Optional Module

- 4x 10/100/1000 Mbps, RJ45 Port

- 4x 10/100/1000 Mbps, M12 Port

PoE+

Optional Module

- 4x PoE+, Individual port 25.5W (with CMI-LAN01, RJ45 Port)

- 4x PoE+, Individual port 25.5W, (with CMI-M12LAN01, M12 Port)

Serial Port

Optional Module

- 2x RS-232/422/485, DB9 Connector

- 4x RS-232/422/485, DB9 Connector

Isolated DIO

Optional Module

- 16x Optical Isolated DIO(8DI, 8DO), 20 pin Terminal Block

Power Ignition Sensing

Optional Module

- CFM with Delay Time Management and Selectable 12V/24V, Dip Switch

Power Adapter

Optional AC/DC Adapter

- AC/DC 24V/5A, 120W

- AC/DC 24V/9.2A, 220W
