Spec Item

Description

Form factor

SBC Form Factor

CPU:

Intel® Celeron® N3160 processor (up to 2.24GHz, quad-core, 2MB cache, TDP=6W)

Chipset:SoC

System Memory:

2 x 204-pin DDR3L 1.35V SDRAM SO-DIMM (system Max : 8GB)

I/O Interface

I/O Ports

4 x USB 3.0

Ethernet:

2 x RJ-45 PCIe GbE by Intel® I210-IT

COM Port:

6 x RS-232, 2 x RS-232/422/485

Display:1 x VGA, 1 x HDMI

Resolution:

VGA: Up to 2560 x 1600, HDMI: Up to 3840 x 2160

Audio:1 x Line-out, 1 x Mic-in

Wireless:1 x 802.11 b/g/n (optional)

Expansion Slots

Expansion Slots

PCIe Mini:1 x Full size (support mSATA, co-lay SATA), 1 x Half size

System

Cooling method / System Fan

Fanless

Drive Bays

1 x 2.5' SATA 6Gb/s HDD/SSD Bay

Color

Color

Black C + Silver

Dimensions

Dimensions

184 x 200.6 x 58.2

Weight

Weight

2.2 kg/3 kg

Environment

Operating Temperature

-40°C ~ 60°C with air flow (SSD)

Humidity

10% ~ 95%, non-condensing
