Spec Item

Description

Form factor

SBC Form Factor

CPU:

Intel® Atom? D525 dual-core 1.8GHz/1MB L2 cache(for ECW-281B-D252)

Intel® Atom? N270 1.6 GHz with 533 MHz FSB(for ECW-281B-N270)

Chipset:

Intel® ICH8M(for ECW-281B-D252)

Intel® 945GSE + ICH7M(for ECW-281B-N270)

System Memory:

1 GB DDR3 204-pin SO-DIMM memory pre-installed(for ECW-281B-D252)

1 GB DDR2 200-pin SO-DIMM memory pre-installed(for ECW-281B-N270)

I/O Interface

I/O Ports

4 x USB 2.0

Ethernet:2 x Realtek 8111E PCIe GbE

COM Port

6 x RS-232 ports for ECW-281B-D525

(COM2: Default RS-232, RS422/485 optional)

6 x RS-232 ports for ECW-281B-N270

(COM2: Default RS-232, RS422/485 optional)

Display:1 x VGA

Resolution:

VGA: Up to 2048 x 1536@60Hz(for ECW-281B-D525)

VGA: Up to 1920 x 1200@60Hz(for ECW-281B-N270)

Audio:1 x Speaker out

Expansion Slots

Expansion Slots

1 x PCIe Mini card slot

System

Cooling method / System Fan

Fanless

Drive Bays

1 x 2.5"" SATA HDD space

Color

Color

Black

Dimensions

Dimensions

229 x 132 x 64

Weight

Weight

2.1 kg/3.9 kg

Environment

Operating Temperature

20°C ~ 65°C with CompactFlash®/SSD(for ECW-281B-D525)

-10°C ~ 50°C with HDD

-10°C ~ 60°C with CompactFlash®/SSD(for ECW-281B-N270)

-10°C ~ 50°C with HDD
