Spec Item

Description

Form factor

SBC Form Factor

Intel® Atom? E3800 series on-board SoC

I/O Interface

I/O Ports

1 x USB 3.0

3 x USB 2.0

2 x RJ-45 (Intel® I210-IT PCIe controller)

2 x RS-232 (RS-232 pin header is optional)

1 x RS-422/485 (pin header, optional)

1 x VGA (up to 2560x1600@60Hz)

1 x Audio Line-out

1 x Audio Mic-in

802.1b/g/n 2T2R (optional)

Expansion Slots

Expansion Slots

2 x Full-size PCIe Mini slot

1 x E-Window

System

Cooling method / System Fan

Refer to MB

Drive Bays

1 x 2.5’’ SATA 6Gb/s HDD/SSD drive bay

Indicator&Buttons

Indicators

Power, HDD

Physical Characteristics

Construction

Aluminum alloy with heavy duty metal

Desktop, wall mount

Color

Color

Black

Dimensions

Dimensions

190 x 140 x 46

Weight

Weight

1.2 kg/2.2 kg

Environment

Operating Temperature

E3845 (10W):

-40°C ~ 50°C without fan module/

-40°C ~ 75°C with fan module

E3825 (6W):

-40°C ~ 65°C without fan module
