Spec Item

Description

Display

Backlight MTBF(hrs)

50000

Brightness(cd/m2)

300

Contrast Ratio

5000:1

LCD Size

24"

Max Resolution

1920(W) x 1080(H)

Environment

Humidity

10% to 95% (non-condensing)

Operating Temperature

-15°C~55°C

Storage Temperature

-20°C~60°C

I/O Interface

I/O Ports and Switches

DVI-D Signal Input: 2 x DVI (24-pin, female)

VGA Signal Output: 1 x D-sub (15-pin, female) - Clone of VGA IN*

Composite Video Input: 1 x BNC connector (female)

LCD

LCD Color

16.7M

Pixel Pitch (mm)

0.3075mm x 0.3075mm

Viewing Angle (H-V)

178° / 178°

Physical Characteristics

Cutout Dimensions

576 mm x 358 mm

Dimensions (LxWxH) (mm)

592 mm x 374 mm x 113 mm

Touch

Touch Controller

6H

Touch Screen

EXC7200 (2-point)

Weight

Weight

11.48 Kg

I/O Interface

I/O Interface

1 x LAN(RJ-45)

2 x Power In(100)

1 x RS-422/485

1 x Touchscreen(UUSB Type A connector (female))

2 x BNC(Input/Output)

1 x Buzzer

3 x VGA(Input x 2/Output x 1)

2 x DVI-D
