Spec Item

Description

Display

Backlight MTBF(hrs)

50000

Brightness(cd/m2)

300

Contrast Ratio

2000:1

LCD Size

19"

Max Resolution

1280(W) x 1024(H)

Environment

Humidity

10% to 95% (non-condensing)

Operating Temperature

-15°C~55°C

Storage Temperature

-20°C~60°C

I/O Interface

I/O Ports and Switches

DVI-D Signal Input: 2 x DVI (24-pin, female)

VGA Signal Output: 1 x D-sub (15-pin, female) - Clone of VGA IN*

Composite Video Input: 1 x BNC connector (female)

RAM

4GB 1600MHz DDR3 SDRAM (2GB*2)

Two 204-pin 1600/1333 MHz dual-channel DDR3 SDRAM support up to 16GB

LCD

LCD Color

16.7M

Pixel Pitch (mm)

0.294mm x 0.294mm

Viewing Angle (H-V)

178° / 178°

Physical Characteristics

Cutout Dimensions

576 mm x 358 mm

Dimensions (LxWxH) (mm)

592 mm x 374 mm x 113 mm

System

Chipset

Intel® QM87

CPU

Intel® 22nm 4th generation Mobile Core? i5-4400E 2.7GHz processor

HDD

1 x 2.5" SATA HDD bay

SSD

CF Type II

Touch

Touch Controller

6H

Touch Screen

EXC7920 (10-point)

Weight

Weight

13.03Kg

I/O Interface

I/O Interface

2 x LAN(RJ-45 for Gbe)

1 x Line in

1 x Line out

1 x Mic

1 x PS/2

1 x Power Switch

1 x RS-232((non-isolated))

4 x RS-422/485((2.5 kv isolation protection))

2 x USB2.0

2 x USB3.0

1 x HDMI

1 x DVI-D

1 x Power In(Isolated 18-36V DC terminal block)

2 x CAN-bus(terminal block)

2 x Antenna SMA((reserved))

1 x VGA
