Spec Item

Description

Form factor

SBC Form Factor

CPU: Intel® Atom? processor E3826 (dual-core, 1.46 GHz, 7W)

Chipset: SoC

System Memory:On-board 2 GB SDRAM

I/O Interface

I/O Ports

20-pin Connector:

1 x GbE LAN

1 x OBD-II/CAN bus

1 x USB 2.0

24-pin Connector:

1 x Audio line-out (R+L)

1 x Audio line-in

1 x RS-232

4-bit digital I/O (2-bit input, 2-bit output)

1 x USB 2.0

1 x USB3.0

1 x HDMI

2 x SIM slot

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini (reserved for mSATA module),

1 x Full-size PCIe Mini (reserved for 3G module),

1 x Half-size PCIe Mini (reserved for Wi-Fi module)

System

Cooling method / System Fan

Fanless

Indicator&Buttons

Indicators

Power/HDD/Wi-Fi/3G

Color

Color

Black C + Silver

Dimensions

Dimensions

210 x 154 x 28

Weight

Weight

0.9 kg/2.1 kg

Environment

Operating Temperature

-20°C ~ 60°C with air flow

Humidity

5% ~ 95%, non-condensing
