Spec Item

Description

System

Cooling method / System Fan

Fanless

CPU

6th generation Intel® mobile ULT Core? i7-6600U / Core? i5-6300U /Celeron® 3855U

7th generation Intel® mobile ULT Kaby Lake on-board SoC (by project base)

Storage

1 x 2.5” SATA 6Gb/s HDD bay

1 x mSATA (E-Window)

Communication

Bluetooth

V4.1 (M.2 2230 A-E key module)

Wi-Fi

IEEE 802.11 a/b/g/n/ac 2T2R module

I/O Interface

Audio

2 x 3W Speaker

Expansion

1 x PCIe Mini reserved for E-Window expansion

RAM

Two 260-pin 1600/1333MHz dual-channel DDR4 SO-DIMM, 4GB pre-installed (system max. 32GB)

I/O Ports and Switches

1 x RJ-11 for 1D/2D barcode reader

4 x USB 2.0 (2 on the side)

4 x USB 3.0 port

1 x HDMI output

2 x GbE LAN port

1 x RS-232/422/485

1 x 12~28V DC jack

Environment

Operating Temperature

0°C~40°C

Humidity

10% to 95% (non-condensing)

Storage Temperature

-20°C~60°C

IP Level

IP65 compliant front panel

Physical Characteristics

Mounting

Wall, Stand and Arm VESA 100/75

Dimensions (LxWxH) (mm)

594.6 x 379.6 x 60.68

Construction Front Panel

ABS+PC plastic with anti-bacterial material

Weight

Weight

7.5 Kg

LCD

Size

24”

Resolution

1920 (W) x 1080 (H)

Brightness (cd/m2)

250

Contrast Ratio

1000:1

LCD Color

16.7M colors (RGB 6-bit + HI_FRC)

Pixel Pitch (mm)

0.2745 (H) x 0.2745 (V)

Viewing Angle (H-V)

178°(H) / 178°(V)

Backlight MTBF

30000 (LED backlight)

Touch

Touch Screen

Projected capacitive type with 10-point multi-touch

Other Features

Camera

5-megapixel CMOS front-facing camera with auto-focus and digital microphone

System Cooling

Fanless

Microphone

digital microphone

Function Key

Function Key

1 x LCD on/off

1 x Brightness up

1 x Brightness down

1 x Volume up

1 x Volume down

1 x Touch lock button for cleaning

Combinations:

1 x Lock/Unlock OSD

1 x Power on/off
