Spec Item

Description

Communication

Wi-Fi

IEEE 802.11b/g/n

Dimensions

Dimensions

310 x 265 x 52.6

Environment

Operating Temperature

-20°C~50°C with SSD

Storage Temperature

-20°C~60°C

I/O Interface

RAM

Support one 204-pin DDR3 SO-DIMM slot (Max. 4GB)

I/O Ports and Switches

1 x RS-232 (DB-9)

1 x RS-232 (RJ-45)

1 x RS-422/485 (4-pin box header)

2 x GbE LAN (RJ-45)

2 x USB 2.0

2 x USB 3.0

1 x Mini USB 2.0 port on front panel

1 x Audio jack (line-out)

LCD

Size

12.1"

Resolution

1024 x 768

Brightness (cd/m2)

600

Contrast Ratio

700:1

LCD Color

16.2M

Pixel Pitch (mm)

0.240 (H) x 0.240 (V)

Viewing Angle (H-V)

160º/140º

Backlight MTBF

50000 (LED backlight panel)

Other Features

Camera

2 M pixels with low light function

System Cooling

Fanless

Power

Power Requirement

9~36 VDC

Storage

Storage

2.5" SATA 6Gb/s SSD bay

System

CPU

2nd Generation Intel® Core? i7/ i5/ i3 and Celeron® processor

Chipset

Intel® HM65

Touch

Touch Screen

5-wire rsistive type with RS-232 interface

Touch Controller

PenMount DMC9000 / EETI EXC7200 & EXC5400

Weight

Weight

3.8Kg

I/O Interface

I/O Interface

1 x AT/ATX switch

1 x Audio((line-out))

1 x Clear CMOS Button

1 x DC Input Jack

1 x HDMI

2 x LAN(GbE LAN (RJ-45))

2 x USB 3.0

1 x Mini USB 2.0(on front panel)

1 x Power Switch

2 x RS-232((DB-9)/(RJ-45))

1 x RS-422/485((4-pin box header))

1 x Reset Button

2 x USB 2.0

1 x MicroSD card slot(on front panel)
