Spec Item

Description

Display

Backlight MTBF(hrs)

50000

Brightness(cd/m2)

500

Contrast Ratio

20.8340277778

LCD Size

8”(4:3)

Max Resolution

800(W) x 600(H)

Environment

Humidity

10% to 95% (non-condensing)

IP Level

Front IP 65

Operating Temperature

-10°C~50°C (14°F~122°F)

Safety & EMC

CE & FCC Class A certified

Storage Temperature

-20°C~60°C (-4°F~140°F)

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini slot (with mSATA/PCIe/USB signal)

1 x Full-size/Half-size PCIe Mini slot (PCIe signal only)

I/O Interface

I/O Ports and Switches

1 x RJ-45 LAN port

1 x RS-232 COM port (DB-9 connector)

(RI/5V/12V)

1 x RS-422/485

2 x USB 3.0

1 x 9 V~30 V DC lockable DC jack (2-pin)

1 x Audio port (line-out)

1 x Power switch

LCD

LCD Color

16.2M

Pixel Pitch (mm)

0.2025 (H) x 0.0675 (V)

Viewing Angle (H-V)

140° / 120°

Physical Characteristics

Color

Black C

Construction

Aluminum front bezel

Cutout Dimensions

207 x 154

Dimensions (LxWxH) (mm)

182.2 x 222.2 x 44

Mounting

Stand, panel mount, rack mount,

VESA 75x75

Power

Power adapter

9V~30VDC

System

CPU

Intel® Celeron® J1900 quad-core on-board SoC, 2GHz

SSD

mSATA

Touch

Touch Screen

5-wire resistive type flat touchscreen

Weight

Weight

1.17 kg

I/O Interface

I/O Interface

1 x AT/ATX Switch

1 x Audio(line-out)

2 x LAN(GbE)

1 x Power In(9-30V Lockable power jack)

1 x Power Switch

1 x RS-232(RJ-45)

1 x RS-422/485(DB-9)

1 x Reset Button

2 x USB3.0
