Spec Item

Description

Display

Backlight MTBF(hrs)

50000

Brightness(cd/m2)

500

Contrast Ratio

29.1673611111

LCD Size

12.1"

Max Resolution

1024(W) x 768(H)

Environment

Humidity

10% to 95% (non-condensing)

Operating Temperature

-10°C~50°C

Storage Temperature

-20°C~60°C

Expansion Slots

Expansion Slots

1 x PCIe Mini card

I/O Interface

I/O Ports and Switches

2 x RS-232

1 x RS-232 (alternative to RS-422/485)

2 x RJ-45 for LAN port

2 x USB 2.0

1 x VGA port

1 x Line-in, 1 x Line-out, 1 x Mic-in

RAM

One 200-pin SO-DIMM socket, supporting DDR2 533MHz module for up to 2GB

LCD

LCD Color

262K

Pixel Pitch (mm)

0.3075mm x 0.3075mm

Viewing Angle (H-V)

160° / 160°

Other Features

System Cooling

Fanless

Physical Characteristics

Cutout Dimensions

313 x 233

Dimensions (LxWxH) (mm)

340 x 277 x 73.4

Power

Power adapter

P/N: 63040-010060-110-RS

60W power adapter (Meets PSE)

Input: 90VAC~264VAC, 50/60Hz

Output: 12VDC

System

Chipset

Intel® 945GSE + ICH7M

CPU

Intel® Atom? N270 1.6GHz CPU

HDD

1 x 2.5” SATA HDD bay

SSD

1 x mSATA (SATA2 signal)

Touch

Touch Controller

EETI MBMER4050CMBG

Touch Screen

5-wire resistive type with RS-232 interface

Weight

Weight

6 kg / 8kg

I/O Interface

I/O Interface

1 x Power Switch

1 x Mic

1 x Line out

1 x Line in

2 x LAN(RJ-45)

1 x Power In(12V DC jack)

2 x RS-232

1 x RS-422/485

2 x USB2.0

1 x VGA

1 x PS/2
