Spec Item

Description

Dimensions

Dimensions

414 x 328.4 x 51.9

Display

Backlight MTBF(hrs)

70000

Brightness(cd/m2)

450

Contrast Ratio

33.3340277778

LCD Size

15”

Max Resolution

1024x768

Environment

IP Level

IP69K

Operating Temperature

-20°C ~ 50°C

Storage Temperature

-30°C ~ 60°C

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot (SATA 6Gb/s)

1 x Full-size/half-size (PCIe x1 and USB 2.0 signals)

1 x M.2 B-key slot (2242/2260/2280 with USB 3.0, PCIe x2 and SATA signals)

I/O Interface

Ethernet

2 x PCIe GbE by Intel® I210 controller

Power

Power adapter

60W/12V waterproof power adapter

VAC:90V~264V; 12V/5A; 60W

Power consumption

43W

Power Requirement

9-36V DC

System

Chipset

Intel® Skylake ULT

CPU

6th generation Intel® Core? i5 and Celeron® ULT processor

Memory Ext.

4GB

Memory Max.

32GB

Storage

1 x 2.5” SATA SSD bay

1 x mSATA

1 x M.2 B-key (2242/2260/2280)

I/O Interface

I/O Interface

1 x DC Input Jack(5-pin M12)

2 x LAN(8-pin M12 X-Code)

1 x Power Switch

2 x RS-232(8-pin M12)

2 x USB 2.0(8-pin M12)
