規格

描述

顯示

背光 MTBF(hrs)

50000

亮度(cd/m2)

400

對比度

41.6673611111

LCD 尺寸

18.5”

最大分辨率

1366x768

運行環境

濕度

5% ~95%, non-condensing

IP 等級

IP66 compliant front panel

操作溫度

-20°C ~ 50°C (with SSD and TDP 65W processor)

-20°C ~ 40°C (with HDD or add-on cards without fan)

Safety & EMC

CE, FCC, CCC

存儲溫度

-30°C ~ 60°C

擴展插槽

擴展插槽

2 x PCIe 3.0 by 8 (by 16 slot)

2 x PCIe 3.0 by 4 ( maximum card size supported: 68 mm x 167 mm)

規格

規格

8th Genertion Intel CoreTM i7/i5/i3 porcessors in the LGA 1151

Intel® 300 Series Chipsets Q370

I/O 接口

以太網

Intel® I211AT Ethernet controllers

其它特征

TPM

Support(2x10pin, P=2.54mm)

物理特性

顏色

Front frame: Cyan-blue (PSM 296C); Others: Black C

切口尺寸

447.8x267.2

尺寸 (LxWxH) (mm)

470x290x121

安裝

Panel/Rack mount

凈重

8.5

電源

電源

AC input ATX power supply

1. 250 W power supply

- Input: 115VAC~230VAC, 50/60Hz

- Output (max.): 3.3V@12A, 5V@14A, 12V@25A, -12V@0.3A,+5Vsb@3A

2. 350 W power supply (Build to Order)

- Input: 115VAC~264VAC, 50/60Hz

- Output (max.): 3.3V@14A, 5V@16A, 12V@29A, -12V@0.3A,+5Vsb@3A

- Efficiency: Full load (100%) 87%, Typical load (50%) 90%, Light load (20%) 87%

存儲

存儲

4 x Hot-swappable SATA 6G/s HDD/SSD bay (support RAID 0/1/5/10)

2 x M.2 M-key (2280, PCIe 3.0 x4), support NVMe SSD

系統

芯片組

Intel® 300 Series Chipsets Q370

散熱方式 / 系統風扇

System fan

CPU

8th Generation LGA1151 Intel® Core? i7/i5/i3 and Pentium® CPU

最大內存

Two 288-pin 2666/2400 MHz dual-channel unbuffered DDR4 SDRAM DIMM slots (system max. 64 GB)

觸摸

觸摸控制器

EETI EXC3188

觸摸屏

10-point Projected capacitive touch window, 6H (Anti-UV, Anti-glare Surface)

I/O 接口

I/O 接口

1 x AT/ATX switch

1 x HDMI

2 x LAN

1 x Line out

1 x Mic

1 x Power Switch

1 x Reset Button

2 x RS-232

6 x USB 3.0
