Spec Item

Description

Form factor

SBC Form Factor

CPU:

Intel® Atom? E3845 1.91 GHz

Chipset:SoC

System Memory:

One 2 GB 204-pin DDR3L SO-DIMM pre-installed

(system max: 8 GB)

I/O Interface

I/O Ports

2 x USB 3.0

2 x USB 2.0

Ethernet:

2 x RJ-45

1 x PCIe GbE by Intel® I210 controller

1 x PCIe GbE by Intel® I211 controller

COM Port:

2 x DB-9 w/3KV isolation protection

2 x DB-9 w/3KV isolation protection

8-bit digital I/O, 4-bit input/4-bit output

1 x VGA, 1 x HDMI

802.1 b/g/n 2T2R (optional)

Expansion Slots

Expansion Slots

1 x Half-size PCIe Mini slot (w/o USB signal)

1 x Full-size PCIe Mini slot (supports mSATA, colay with SATA)

System

Cooling method / System Fan

Fanless

Drive Bays

Indicator&Buttons

1 x 2.5〞 SATA 6Gb/s HDD/SSD Bay

Indicators

Power/HDD/Com port/DIO

Color

Color

Black

Dimensions

Dimensions

74.08 x 140 x 171.5

Weight

Weight

1.4 kg/2.5 kg

Environment

Operating Temperature

-20°C ~ 60°C with air flow (SSD)

Humidity

5% ~ 95%, non-condensing
