Spec Item

Description

Form factor

SBC Form Factor

CPU:Intel® Core? i5-6300U processor (dual-core, 2.4 GHz, 15W TDP)

Chipset:SoC

System Memory:2 x 260-pin DDR4L SO-DIMM 4GB pre-installed (system max. 32 GB)

I/O Interface

I/O Ports

2 x USB 3.0

1 x USB 2.0 (M12 connector)

2 x M12 connector PCIe GbE by Intel® I1211

2 x DB-9 RS-232/422/485 (with 1.5 kV isolation)

1 x Terminal block for 8-bit digital I/O (4-bit input/4-bit output, 1.5 kV isolation)

1 x VGA

1 x DVI-D

1 x Line-out, 1 x Mic-in

2 x SIM card slot

Expansion Slots

Expansion Slots

2 x Full-size PCIe Mini (for WWAN / WLAN module)

System

Cooling method / System Fan

Fanless

Drive Bays

2 x 2.5' SATA 6Gb/s SSD drive bay

Color

Color

Blue C

Dimensions

Dimensions

290 x 69 x 225

Weight

Weight

3.9 kg / 5.1 kg

Environment

Operating Temperature

-40°C ~ 70°C with air flow (with industrial SSD/CF), compliant with EN 50155

Humidity

10% ~ 95%, non-condensing
