Spec Item

Description

Form factor

SBC Form Factor

CPU: Intel® mobile Core? i5-4400E (2.7 GHz, 37W)

Chipset: Intel® QM87

System Memory: 2 x 204-pin DDR3 SO-DIMM slot

(system max. 16 GB)

Pre-installed 4 GB DDR3 SO-DIMM

I/O Interface

I/O Ports

1 x PS2 (KB/MS)

2 x USB3.0

2 x USB2.0

2 x RJ-45 with teaming support

1 x PCIe GbE by Intel® I217LM

1 x PCIe GbE by Intel® I210-AT

(2 with 2 kV isolation)

1 x DB-9 (non-isolated)

4 x RS-232/422/485 (with 2.5 kV isolation)

2 x CAN-bus (with 2.5 kV isolation)

1 x VGA

1 x DVI-D

1 x HDMI

Expansion Slots

Expansion Slots

2 x Full size

System

Cooling method / System Fan

Fanless

Drive Bays

2 x 2.5” SATA 6Gb/s SSD bay with RAID 0/1 function

Indicator&Buttons

Indicators

Power (power on: green, power off: orange), storage (red, blinking), IPMI (blue)

Color

Color

Black

Dimensions

Dimensions

290 x 75 x 225

Weight

Weight

4.08 kg / 6.03 kg

Environment

Operating Temperature

-15°C ~ 55°C with air flow

Humidity

5% ~ 95%, non-condensing
