Spec Item

Description

Form factor

SBC Form Factor

CPU: Intel® Skylake ULT /Baytrail processor

Chipset: SoC

System Memory:2 x 204-pin DDR3L SO-DIMM. 1 x 4GB pre-installed

I/O Interface

I/O Ports

2 x USB3.0

4 x PoE IEEE802.3af (one port max 15.4W)

2 x DB-9 RS-232

1 x DB-15 isolated RS-422/485

Isolated 8-bit digital I/O (4-bit input, 4-bit output)

1 x DB9 CAN-Bus/OBD-II

1 x VGA

1 x HDMI

1 x Mic in, 1 x Line out

2 x SIM slot

Expansion Slots

Expansion Slots

1 x Half-size PCIe Mini (reserved for Wi-Fi)

1 x Full-size PCIe Mini (reserved for 3G)

1 x Full-size PCIe Mini (only for skylake platform)

System

Cooling method / System Fan

Fanless

Drive Bays

2 x 2.5"" SATA 3Gb/s HDD/SSD drive bay

Indicator&Buttons

Indicators

8 x LED (4 PoE, 1 HDD, 1 Wi-Fi, 2 SIM)

Color

Color

Blue C

Dimensions

Dimensions

255 x 80 x 185

Weight

Weight

3kg/4.5kg

Environment

Operating Temperature

-20°C ~ 60°C with air flow

Humidity

5% ~ 95%, non-condensing
