Spec Item

Description

Form factor

SBC Form Factor

CPU: Intel® Core i5-5350U (dual-core, 1.8 GHz, 15W TDP) or

Intel® Celeron® 3765U (dual-core, 1.9 GHz, 15W TDP)

Chipset: SoC

System Memory:2 x 204-pin DDR3L SO-DIMM. 1 x 4GB pre-installed

I/O Interface

I/O Ports

2 x USB3.0

2 x USB2.0

4 x RJ-45 GbE Lan

2 x DB-9 RS-232/422/485

3 x DB-9 RS-232 (optional)

1 x VGA

1 x HDMI

8 bit digital I/O (4-bit input, 4-bit output) (optional)

1 x SIM slot

1 x Line out, 1 x Mic in

Expansion Slots

Expansion Slots

1 x Full size (co-lay mSATA)

1 x Half size

System

Cooling method / System Fan

Fanless

Drive Bays

1 x 2.5"" SATA 3Gb/s HDD/SSD drive bay

Indicator&Buttons

Indicators

HDD/Power

Color

Color

Blue C

Dimensions

Dimensions

255 x 63 x 150

Weight

Weight

2.2 kg/3 kg

Environment

Operating Temperature

-20°C ~ 60°C with air flow

Humidity

5% ~ 95%, non-condensing
