Spec Item

Description

Form factor

SBC Form Factor

CPU:

Intel® Celeron® J1900 2 GHz

Chipset:SoC

System Memory:

One 204-pin DDR3L 1.35V SO-DIMM

2 GB pre-installed (system max: 8G)

I/O Interface

I/O Ports

2 x USB 3.0

2 x USB 3.0

Ethernet:

2 x RJ-45

1 x PCIe GbE by Intel® I210

1 x PCIe GbE by Intel® I211

COM Port:

2 x RS-232 (DB-9)

2 x RS-232/422/485 (DB-9, with isolation)

16-bit digital I/O, 8-bit input/8-bit output

1 x DisplayPort, 1 x DVI-I

1 x Line-out, 1 x Mic-in

Expansion Slots

Expansion Slots

1 x Full size PCIe Mini

PCI/PCIe:

3A: One PCIe x1 + Two x PCI

3B: Two PCIe x1 + One x PCI

3C: Three x PCI

System

Cooling method / System Fan

Fanless

Drive Bays

1 x 2.5' SATA 6Gb/s HDD/SSD Bay

Color

Color

Black C + Silver

Dimensions

Dimensions

136 x 219 x 188

Weight

Weight

2.8 kg/4.3 kg

Environment

Operating Temperature

-20°C ~ 60°C with air flow (SSD)

Humidity

5% ~ 95%, non-condensing
