Spec Item

Description

BIOS

BIOS

AMI UEFI BIOS

CPU Cooler

CPU Cooler

1 x CPU smart fan (1x4 pin)

1 x System fan (1x3 pin)

Dimensions

Dimensions

170mm x 170 mm

Display

Display Output

1 x HDMI 1.4 (up to 4096x2160@24Hz)

1 x HDMI/DP (up to 4096x2160@24Hz)

1 x LVDS/eDP (select by switch)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

External Connector

External Connector

4 x USB 3.0

HW Monitor

HW Monitor

1 x Chassis intrusion connector (1x2 pin)

I/O Interface

Audio I/F

Realtek ALC662 HD Audio Codec support 5.1 Channel

2 x Audio jacks (line-out, mic-in) on rear IO

1 x Front audio (2x5-pin)

Digital I/O

8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I219 (with Intel® AMT11.0 support)

LAN2: Intel® I211 PCIe controller with NCSI support

Expansion

1 x PCIe x4 slot

1 x Full-size PCIe Mini card slot (support mSATA, colay SATA2)

1 x Full-size PCIe Mini card slot (with SIM holder)

*3855U belongs to Skylake ULT Base series CPU, PCIe signal support only PCIe Gen 2

I/O Interface

I/O Interface

4 x RS-232(2x5 pin, P=2.0)

2 x SATA 6Gb/s(5V output)

1 x Front panel(2x7 pin, power LED, HDD LED,power button, reset button)

2 x Internal RS-232/422/485(2x5 pin, P=2.0)

1 x I²C(1 x I²C (1x4 pin))

1 x SMBus(1x4 pin)

2 x LAN LED(1x2 pin)

4 x USB 2.0(2x4 pin, P=2.0)

Internal Connector

Internal Connector

1 x eMMC 5.0 (optional, up to 32G)

4 x RS-232 (2x5 pin, P=2.0)

2 x RS-232/422/485 (2x5 pin, P=2.0)

4 x USB 2.0 (2x4 pin, P=2.0)

2 x SATA with 5V output (RAID 0/1 supported)

Power

Power consumption

12V@4.68A (Intel® Core? i7-6600U up to3.4GHz CPU with 16GB(8GB x 2) DDR4-2133 memory running in 3.2GHz)

Power Supply

9~36V DC input

1 x Internal power connector (2x2 pin)

1 x External DC power Jackc (Ø5.5mm)

Support AT/ATX mode

System

CPU

6th generation Intel® mobile ULT on-board processor

Intel® Core? i7-6600U (up to 3.4GHz, dual-core, 4M Cache, TDP=15W)

Intel® Core? i5-6300U (up to 3.0GHz, dual-core, 3M Cache, TDP=15W)

Intel® Core? i3-6100U (up to 2.3GHz, dual-core, 3M Cache, TDP=15W)

Intel® Celeron® 3955U (up to 2.0GHz, dual-core, 2M Cache, TDP=15W)

Intel® Celeron® 3855U (up to 1.6GHz, dual-core, 2M Cache, TDP=15W)

Graphcis Controller

Intel® HD graphic

Memory Max.

2 x SO-DIMM DDR4 2133MHz, system maximun up to 32GB

Watchdog Timer

Watchdog Timer

Software programmable support 1~255 sec. system reset by Super I/O

Weight

Weight

GW: 900g / NW: 375g
