Spec Item

Description

Display

Display Output

Triple independent display

1 x HDMI/DP (up to 3840x2160@30Hz)

1 x 18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz)

1 x VGA by CH7517 DP to VGA converter (up to 1920x1200@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot

1 x microSD card slot

1 x PCIe x1

I/O Interface

Audio

Realtek ALC662 HD codec

1 x Audio jack (line-out)

1 x Analog audio (2x5 pin)

Digital I/O

1 x 8-bit digital I/O (2x5 pin)

Ethernet

Dual Realtek RTL8111E PCIe GbE controller

I/O Interface

I/O Interface

2 x Internal USB 2.0

4 x Internal RS-232

4 x USB 3.0

1 x KB/MS

2 x Internal RS-232/422/485

Power

Power consumption

12V@1.61A(Intel® Celeron® N3710 CPU with two 4 GB 1600 MHz DDR3L memory)

System

CPU

Intel® Pentium® N3710 on-board SoC (up to 2.56GHz, quad-core, 2MB cache, TDP=6W)

Intel® Celeron® N3160 on-board SoC (up to 2.24GHz, quad-core, 2MB cache, TDP=6W)

Intel® Celeron® N3060 on-board SoC (up to 2.48GHz, dual-core, 2MB cache, TDP=6W)

Intel® Celeron® N3010 on-board SoC (up to 2.24GHz, dual-core, 2MB cache, TDP=4W)

Memory Max.

Two 204-pin 1333/1600 MHz single-channel DDR3L SDRAM unbuffered SO-DIMM slots support up to 8 GB
