Spec Item

Description

Dimensions

Dimensions

170mm x 170mm

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

I/O Interface

Digital I/O

8-bit digital I/O (2x5 pin)

Ethernet

2 x PCIe GbE LAN Realtek RTL8111

Expansion

1 x PCIe x1 slot

1 x Full/Half-size PCIe Mini card slot (w/ SIM holder)

I/O Interface

I/O Interface

4 x Internal RS-232((2 x 5 pin,p=2.0))

2 x Internal RS-232/422/485((2 x 5 pin,p=2.0))

2 x Internal USB 2.0((2 x 4 pin,p=2.0))

1 x KB/MS((1 x 6Pin ))

2 x SATA 6Gb/s

1 x SMBus((1 x 4pin))

System

CPU

Intel® Atom? x7-E3950 on-board SoC (up to 2.0GHz, quad-core, 2M Cache, TDP=12W)

Intel® Atom? x5-E3940 on-board SoC (up to 1.8GHz, quad-core, 2M Cache, TDP=9W)

Intel® Atom? x5-E3930 on-board SoC (up to 1.8GHz, dual-core, 2M Cache, TDP=6W)

Intel® Pentium® N4200 on-board SoC (up to 2.5GHz, quad-core, 2M Cache, TDP=6W)

Intel® Celeron® N3350 on-board SoC (up to 2.4GHz, dual-core, 2M Cache, TDP=6W)

Memory Max.

Two 204-pin 1867/1600MHz Dual-channel DDR3L DIMMs support up to 8GB

Weight

Weight

1100g / NW: 700g
