Spec Item

Description

CPU Cooler

CPU Cooler

CF-989A-RS-R12

Display

Display

Triple display supported

2 x HDMI

1 x DVI-I

1 x18/24-bit dual-channel LVDS

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-10°C ~ 60°C (14°F ~ 140°F)

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini slot

1 x PCIe x16

I/O Interface

Audio

Realtek ALC892 HD codec

Digital I/O

8-bit digital I/O

Ethernet

LAN1: Intel® 82583V PCIe controller

LAN2: Intel® 82579 PHY with Intel® AMT 8.0 support

I/O Interface

2 x RS-232 2 x RS-232

1 x RS-422/485

4 x USB 2.0

4 x USB 3.0

1 x 4-pin wafer for SMBus

1 x KB/MS by 6-pin header

1 x TPM connector (2x10 pin)

I/O Interface

I/O Interface

4 x USB 3.0

4 x USB 2.0

2 x RS-232

1 x RS-422/485

Power

Power consumption

12V@6.08A (2.3GHz Intel® Core? i7- 3610QE with two 1333 MHz 4GB DDR3 memory running 3DMark06 burn in)

System

Chipset

Intel® QM77

CPU

Intel® Mobile processor

CPU Socket

Socket G2

Memory Max.

2 x 204-pin, Max. 16GB, 1066/1333/1600 MHz dual-channel DDR3 SO-DIMMs

Storage

2 x SATA 6Gb/s

2 x SATA 3Gb/s

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
