Spec Item

Description

CPU Cooler

CPU Cooler

GX-415GA (with hearsink)

GX-210HA (with cooler)

Display

Display

Dual display supported

1 x VGA

2 x HDMI

Environment

Humidity

5% ~ 95% non-condensing

Operating Temperature

0°C ~ 60°C (32°F ~ 140°F)

Expansion Slots

Expansion Slots

1 x Half-size PCIe Mini card slot

1 x PCIe x4 slot

I/O Interface

Audio

Realtek ALC892 HD Audio codec

Digital I/O

8-bit Programmable I/O (8-bit GPIO is for programming I/O)

Ethernet

LAN1: Intel® I210-AT PCIe controller with NCSI support

LAN2: Intel® I211-AT PCIe controller

I/O Interface

1 x RS-422/485

4 x RS-232

2 x USB 3.0

4 x USB 2.0

1 x 6-pin wafer for PS/2 KB/MS

I/O Interface

I/O Interface

2 x USB 3.0

1 x RS-422/485

4 x USB 2.0

4 x RS-232

Option

iRIS

1 x iRIS-2400 slot

Power

Power consumption

12V@ 1.45A (AMD GX-415GA 1.5GHz CPU with 1333MHz 2GB DDR3 memory)

System

Chipset

AMDR Embedded G-Series SoC

CPU

AMDR Embedded G-Series SoC

CPU Socket

On board

Memory Max.

Two 204-pin 1600/1333MHz dualchannel DDR3 & DDR3L SDRAM unbuffered DIMMs (system max. 8GB)

Storage

2 x SATA 6Gb/s with SATA power connector

1 x mSATA (colay SATA port 2)

1 x SD card

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
