Spec Item

Description

Dimensions

Dimensions

170mm x 170mm

Display

Display Output

VGA (up to 1920x1200@60Hz)

18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz)

Dual HDMI (up to 2500x1600@60Hz)

iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 3840x2160@60 Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

1 x RS-232

2 x USB 2.0

2 x USB 3.0

I/O Interface

Audio

Realtek ALC662 HD Audio codec

Digital I/O

8-bit digital I/O (4-bit input, 4-bit output)

Ethernet

GBE1: Intel® I217LM with Intel® AMT 9.0 support GBE2: Intel® I210-AT PCIe controller

I/O Interface

I/O Interface

1 x Internal RS-232/422/485

2 x Internal USB 3.0

6 x Internal USB 2.0

1 x KB/MS

4 x Internal RS-232

Option

iRIS

1 x iRIS-1010 slot

Power

Power consumption

12V@6.03A (Intel® Core? i7-4770EQ, 2.4GHz CPU with 8 GB (two 4 GB) 1333 MHz DDR3 memory)

System

Chipset

Intel® QM87

CPU

Intel® mobile Core? i7-4700EQ on-board processor with Intel® AMT 9.0 support (2.4GHz, quadcore, 6MB cache, TDP=47W)

Intel® mobile Core? i5-4402E on-board processor with Intel® AMT 9.0 support (1.6GHz, dual-core, 3MB cache, TDP=25W)

Intel® mobile Core? i3-4102E on-board processor (1.6GHz, dual-core, 3MB cache, TDP=25W)

Intel® mobile Celeron® 2002E on-board processor (1.5GHz, dual-core, 2MB cache, TDP=25W)

Intel® mobile Core? i5-4400E on-board processor with Intel® AMT 9.0 support (2.7GHz, dual-core, 3MB cache, TDP=37W)(by request)

Intel® mobile Core? i3-4100E on-board processor (2.4GHz, dual-core, 3MB cache, TDP=37W)(by request)

Intel® mobile Celeron® 2000E on-board processor (2.2GHz, dual-core, 2MB cache, TDP=37W)(by request)

Memory Max.

Two 204-pin 1066/1333/1600 MHz DDR3 dual-channel SO-DIMMs (support up to 16 GB)
