Spec Item

Description

CPU Cooler

CPU Cooler

CF-1156A-RS-R11

CF-1156C-RS

CF-1156D-RS

CF-1156E-R11

Display

Display

VGA (up to 1920x1200@60 Hz)

DVI-D (up to 2560x1600@60 Hz)

iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 3840x2160@60 Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

1 x PCIe x1 slot

1 x Full-size PCIe Mini card slot (supports mSATA, SATA 3Gb/s signal only)

I/O Interface

Audio

Realtek ALC662 HD Audio codec

2 x Audio jacks (line-out, mic-in) on rear IO

1 x Front audio (2x5-pin)

Digital I/O

8-bit digital I/O (2x5 pin)

Ethernet

Dual LAN: Intel® I211-AT PCIe controller

I/O Interface

I/O Interface

3 x Internal RS-232

2 x USB 3.0

2 x USB 2.0

1 x Internal RS-422/485

4 x Internal USB 2.0

2 x RS-232

Power

Power consumption

+12V@6.03A(Intel® Core? i7-4770K 3.90 GHz CPU with two 1333 MHz 4 GB DDR3 memory)
