Spec Item

Description

CPU Cooler

CPU Cooler

CF-1156A-RS-R11

CF-1156C-RS

CF-1156D-RS

CF-1156E-R11

Display

Display

Dual display supported

1 x VGA

1 x HDMI

1 x DVI-D

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-10°C ~ 60°C (14°F ~ 140°F)

Expansion Slots

Expansion Slots

1x PCI Slot

1x PCIe x1 slot

I/O Interface

Audio

Realtek ALC662 HD Audio codec

Digital I/O

8-bit digital I/O

Ethernet

LAN1: Realtek RTL8111E PCIe GbE controller with ASF 2.0 support

LAN2: Realtek RTL8111E PCIe GbE controller

I/O Interface

1 x RS-232

1 x RS-422/485

10 x USB 2.0

1 x KB/MS by 6-pin header

1 x TPM connector (2x10 pin)

I/O Interface

I/O Interface

10 x USB 2.0

1 x RS-232

1 x RS-422/485

Power

Power consumption

1+2V@5.07A (2.2GHz Intel® G620T with 2GB*2 DDR3 1066MHz running 3DMark06 burn in) 12V@8.85A (2.8GHz Intel® Core? i7- 2600S with two 1066MHz 2GB DDR3 running 3DMark06 burn in)

System

Chipset

Intel® H61

CPU

Intel® Core? i3, PentiumR, Celeron® processor

CPU Socket

Socket H2

Memory Max.

2 x 204-pin, Max.16GB, 1066/1333 MHz dual-channel DDR3 SO-DIMMs

Storage

4 x SATA 3Gb/s

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
