Spec Item

Description

CPU Cooler

CPU Cooler

N/A

Display

Display

Dual independent display

VGA (up to 2560x1600@60 Hz)

DVI-D (up to 1920x1080@60 Hz)

iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 2560x1600@60 Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot 1 x microSD slot (E38XX SKU only)

1 x PCIe x4 slot (with PCIe x1 signal) 1 x mSATA share with SATA port 2

I/O Interface

Audio

Realtek ALC662 HD Audio codec supports 5.1-channel

3 x Audio jacks (line-out, line-in, mic-in) on rear IO

1 x Front audio (2x5-pin)

Digital I/O

8-bit digital I/O (2x5 pin)

Ethernet

Dual Realtek RTL8111E PCIe GbE controller

I/O Interface

I/O Interface

2 x USB 3.0

2 x USB 2.0

4 x Internal USB 2.0

1 x Internal RS-422/485

3 x Internal RS-232

2 x RS-232

Power

Power consumption

12V@1.64A (Intel® Celeron® J1900 CPU with 4 GB 1333 MHz DDR3L memory)

System

CPU

Intel® Celeron® J1900 on-board SoC (2GHz, quad-core, 2MB cache, TDP=10W)

Memory Max.

2 x 204-pin 1066/1333 MHz dual-channel DDR3L SO-DIMM supported (system max. 8

GB)

Storage

2 x SATA 3Gb/s with 5V, 12V SATA power connector

Watchdog Timer

Watchdog Timer

Software programmable supports 1~255 sec. system reset
