Spec Item

Description

Dimensions

Dimensions

244mm x 305mm

Display

Display Output

Triple independent display

1 x VGA (up to 1920x1200@60Hz)

1 x DVI-D (up to 2560x1600@60Hz)

1 x HDMI 2.0 (up to 4096x2160@60Hz)

1 x iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 4096x2304@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

I/O Interface

Digital I/O

8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I219LM with Intel® AMT 11.0 support

LAN2: Intel® I210AT PCIe controller

Expansion

1 x Full-size PCIe Mini card slot

2 x PCI slot

2 x PCIe x8 slot (Gen3)

3 x PCIe x4 slot (Gen3)

I/O Interface

I/O Interface

4 x RS-232((2 x 5 PIN,P=2.0))

2 x RS-422/485((2 x 5 PIN,P=2.54))

1 x LPT((2 x 13PIN,P=2.54))

1 x USB 3.0

6 x SATA 6Gb/s

1 x KB/MS((1 x 6PIN))

4 x USB 2.0

Power

Power consumption

3.3V@1.51A, 5V@3.31A, 12V@9.02A, 5VSB@3.7A (Intel® Xeon® E3-1275 v5 3.60 GHz CPU with 32 GB (four 8GB) 2133 MHz DDR4 memory)

Power Supply

ATX/AT power supply

System

Chipset

Intel® C236

CPU

LGA 1151 socket supports Intel® Xeon® E3 v5/v6, 6th/7th generation Core? i3, Pentium® or Celeron® processor

Memory Max.

Four 288-pin 2133 MHz dual-channel DDR4 SDRAM ECC and non-ECC unbuffered DIMMs support up to 64 GB

Weight

Weight

GW:1200g, NW: 700g
