Spec Item

Description

Display

Display Output

VGA (Chrontel 7517)

DVI-I (ASM1442, Chrontel 7517)

LVDS (Chrontel 7511)

iDP

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Expansion Slots

Expansion Slots

1 x PCIe x16 slot (Gen3) 1 x Full-size PCIe Mini card slot 1 x PCIe x1 slot (Gen2) 2 x PCI slot

I/O Interface

Audio

Realtek ALC662 HD Audio Codec support 5.1 Channel, (2 Audio Jack colay 3) Front Audio (2x 5 pin) (Line-in, Line-out, Mic)

Digital I/O

1 x 8-bit digital I/O (2x5 pin)

Ethernet

LAN1: RTL 8111GN controller LAN2: RTL 8111GN controller

I/O Interface

I/O Interface

1 x KB/MS((1 x 6 pin))

1 x LPT((2 x 13pin,P=2.54))

2 x RS-422/485((1 x 4 pin, P=2.0, colay with COM4))

4 x SATA 6Gb/s

2 x Internal USB 2.0((2 x 4pin,P=2.0))

SMBus((1 x 4 pin))

1 x I²C((1 x 4 pin))

1 x SMBus((1 x 4 pin))

10 x Internal RS-232((2 x 5pin,P=2.0))

Power

Power consumption

3.3V@ 0.93A, 5V@2.99A, 12V@6.88A, 5VSB@0.02A (Intel® Core? i7-6700K 4.0GHz CPU with 16GB (two 8GB) 2133 MHz DDR4 memory)

Power Supply

ATX/AT Power Supply

System

Chipset

Intel® skylake H110

CPU

LGA 1151 socket supports Intel® 6th/7th generation Core? i7/i5/i3, Pentium® or Celeron® processor

Memory Max.

Two 288-pin 2133MHz Dual-Channel DDR4 SDRAM Unbuffered DIMM supported up to 64GB

Weight

Weight

GW:1200g, NW: 700g
