Spec Item

Description

CPU Cooler

CPU Cooler

N/A

Display

Display

VGA (up to 2560x1600@60Hz)

LVDS1: 18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz)

LVDS2: 18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz)

Environment

Humidity

10% ~ 95%, non-condensing

Operating Temperature

0°C ~ 40°C with AUPS sub-system -20°C ~ 60°C without AUPS sub-system

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot (with USB 2.0) 1 x PCIe x1

I/O Interface

Audio

Realtek ALC662 HD codec 2 x Audio jacks (rear I/O) Front audio: 1 x 10-pin header

Digital I/O

8-bit digital I/O (4-bit input, 4-bit output)

Ethernet

Dual LAN: Realtek RTL8111E PCIe controller

I/O Interface

I/O Interface

2 x USB 2.0

1 x RS-422/485

4 x RS-232

2 x Internal USB 2.0

2 x USB 3.0

Power

Power consumption

+12V @1.55A (Intel® Celeron® J1900 CPU, 2 x 4GB 1333 MHz DDR3L memory)

System

CPU

Intel® Celeron® J1900 on-board SoC (2GHz, quad-core, 2MB cache, TDP=10W)

CPU Socket

On Board

Memory Max.

Two 204-pin 1066/1333MHz dual-channel unbuffered DDR3L SDRAM SO-DIMM supports up to 8 GB (J1900, N2930, E3845, E3827, E3826) or 4 GB (N2807, E3825, E3815)

Storage

1 x CFast slot 2 x SATA with 5V output

Watchdog Timer

Watchdog Timer

Software programmable supports 1~255 sec.
