Spec Item

Description

Environment

Humidity

5% ~ 95%, noncondensing

Operating Temperature

-40°C ~ 85°C

I/O Interface

Display

Dual independent display

1 x 18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz)

1 x DDI (DP/HDMI, max. resolution 2560x1600/1920x1080)

Ethernet: Intel® I210 GbE

Ethernet

Intel® I210 GbE controller

Expansion

3 x PCIe x1 signal to baseboard

I/O Interface

I/O Interface

1 x USB 3.0

6 x USB 2.0

Power

Power consumption

Power Consumption 3.3V@0.13A, 5V@0.13A, 12V@1.35A, 5VSB@0.12A (Intel® Atom? E3845 CPU with 2 GB onboard memory)

System

CPU

Intel® Atom? E3845 on-board SoC (1.91GHz, quad-core, 2MB cache, TDP=10W)

Memory Max.

2 GB soldered-down 1066/1333 MHz DDR3L memory (up to 4 GB)

Storage

2 x SATA 3Gb/s signal to baseboard Optional soldered-down 4 GB SSD (SATA port 2)

Watchdog Timer

Watchdog Timer

Software programmable supports 1~255 sec. system reset (form EC)
