Spec Item

Description

Dimensions

Dimensions

304.8 mm x 243.8 mm (12＂ x 9.6＂)

Display

Display

1 x VGA from iRIS-2400

Display Output

1 x VGA from iRIS-2400

Environment

Humidity

5% ~ 95%, non-condensing

Storage Temperature

-40°C ~ 85°C

I/O Interface

GPIO

8-bit GPIO

I/O Interface

I/O Interface

1 x Ethernet(RJ-45)

1 x Expansion / Front panel(Power LED, HDD LED, Speaker (Buzzer), Power Button, Reset Button)

1 x I²C(1x4 pin wafer)

2 x RS-232(from COM Express (only TX, RX, GND))

2 x RS-232(from SIO)

2 x SATA 6Gb/s

1 x SMBus(1x4 pin wafer))

4 x USB 3.0

1 x VGA

Option

iRIS

1 x iRIS-2400 slot

Power

Power Supply

ATX / AT Power Supply 24+4 pin

Watchdog Timer

Watchdog Timer

Software programmable, supports 1~255 sec system reset

Weight

Weight

GW:590g / NW:390g
