Spec Item

Description

Display

Display Output

1 x VGA 1 x HDMI (HDMI signal only)

1 x DisplayPort pin-header 1 x DisplayPort connectors

1 x LVDS 18/24-bit single or dual-channel (with PWM back light controller)

Environment

Humidity

5% ~ 95 non-condensing

Operating Temperature

-20°C ~ 60°C

I/O Interface

Expansion

1 x PCIe x16

5 x PCIe x1

1 x LPC

2 x PCIe Mini (MINIPCIE1 colay with m-sata with SATA_4)

I/O Interface

I/O Interface

2 x USB 2.0

2 x USB 3.0

System

CPU

Supports COM Express Compact/Mini module using connector pin out Type 6

Storage

EEPROM (supports EAPI R1.0)
