Spec Item

Description

Dimensions

Dimensions

125 mm x 95 mm

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

Safety & EMC

CE/FCC compliant

Storage Temperature

-30°C ~ 70°C

I/O Interface

Ethernet

Intel® I210 2 x 10G KR interfaces 10G sideband signals (10G_INT 10G_PHY_MDC/MDIO 10G_PHY_SEL 10G_PHY_RST 10G_LED_I2C 10G_SFP_I2C 10G_SDP)

Expansion

1 x PCIe x16 Gen 3 (bifurcatable to 2 x8, 1 x8 & 2 x4, or 4 x4)

1 x PCIe x8 Gen 3 (bifurcatable to 1 x8 & 2 x4)

8 x PCIe x1 (Gen2) signal to base board

Bifurcatable to 1 x8 or 2 x4 or 4 x1+1x4 or 8 x1

GPIO

8-bit GPIO, to base board

I/O Interface

2 x RS-232 (2-wire) to base board

4 x USB 2.0 to base board

4 x USB 3.0 to base board

2 x SATA 6Gb/s signal to base board

I²C

Yes, to base board

I/O Interface

I/O Interface

2 x RS-232((2-wire) to base board)

2 x SATA 6Gb/s(signal to base board)

4 x USB 3.0(to base board)

USB2.0

Power

Power consumption

12V@2.15 A (Intel Xeon D-1518 with two 8 GB SO-DIMM DDR4 2133 MHz memory)

Power Supply

12V: 12VSB±5%

System

CPU

Intel® Xeon® Processor D-1548 (12MB Cache, 2.00 GHz)

Intel® Xeon® Processor D-1518 (6MB Cache, 2.20 GHz)

Intel® Xeon® Processor D-1508 (3MB Cache, 2.20 GHz)

Memory Max.

Two 240-pin 2133/1867 MHz dual-channel DDR4 SDRAM unbuffered DIMM supported (system max. 32GB)

Support ECC

Watchdog Timer

Watchdog Timer

Software programmable, support 1~255 sec. system reset.

Weight

Weight

GW: 600g / NW: 300g
