Spec Item |
Description |
System |
|
CPU |
7th generation Intel® mobile ULT processor |
Intel® Core? i7-7600U (up to 3.9GHz, dual-core, 4MB cache, TDP=15W) |
|
Intel® Core? i5-7300U (up to 3.5GHz, dual-core, 3MB cache, TDP=15W) |
|
Intel® Core? i3-7100U (up to 2.4GHz, dual-core, 3MB cache, TDP=15W) |
|
Memory Max. |
1 x 260-pin 2133MHz DDR4 SDRAM SO-DIMM (channel 1, supports up to 16GB) |
On-board 4GB/8GB DDR4 memory (channel 2, optional support by request) |
|
I/O Interface |
|
Ethernet |
1 x Intel® I219LM |
1 x Intel® I211AT |
|
Digital I/O |
1 x 8-bit digital I/O (2x5 pin) |
Display |
Triple independent display |
1 x VGA (up to 1920x1200@60Hz) |
|
1 x HDMI (up to 4096x2160@30Hz) |
|
1 x 18/24-bit dual-channel LVDS (up to 1920x1200@60Hz) |
|
1 x iDP interface for HDMI, LVDS, VGA, DVI, DP (co-layout with VGA) |
|
Audio |
1 x HD audio (2x5 pin, supports 7.1-channel HD audio by AC-KIT-892HD-R10) |
Expansion |
1 x Full-size PCIe Mini slot (w/ SATA signal, supports mSATA) |
1 x Full-size PCIe Mini slot (w/ SIM card slot support) |
|
*3855U belongs to Skylake ULT Base series which supports PCIe Gen 2 signal only. |
|
Power |
|
Power consumption |
12V@4.27A (Intel® Core? i7-6600U up to 3.4GHz CPU with 16GB 2133MHz DDR4 memory running in 3.0GHz) |
Power Supply |
12V only DC input |
1 x Internal power connector (2x2 pin, or optional terminal block) |
|
Environment |
|
Operating Temperature |
-20°C ~ 60°C |
Safety & EMC |
CE/FCC compliant |
Humidity |
5% ~ 95%, non-condensing |
Storage Temperature |
-20°C ~ 60°C |
Dimensions |
|
Dimensions |
146mm x 102mm |
Weight |
|
Weight |
GW: 600g / NW: 250g |
Watchdog Timer |
|
Watchdog Timer |
Software programmable, supports 1~255 sec. system reset |
I/O Interface |
|
I/O Interface |
4 x USB 3.0(External I/O) 2 x Internal USB 2.0(2x4 pin, P=2.0) 2 x Internal RS-232/422/485(1x9 pin, P=1.25) 1 x SMBus(1x4 pin, P=2.0) 1 x SATA 6Gb/s(6Gb/s with 5V SATA power connector) |
