Spec Item

Description

CPU Cooler

CPU Cooler

N/A

Display

Display

Triple independent display

VGA (up to 2560x1600@60 Hz)

18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-10°C ~ 60°C

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot (mSATA support)

I/O Interface

Audio

Realtek ALC662 HD Audio codec 1 x Analog audio (2x5 pin)

Digital I/O

1 x 8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I218LM PHY with Intel® AMT 9.0 support

LAN2: Intel® I210-AT PCIe controller with NCSI support

I/O Interface

I/O Interface

3 x RS-232

3 x Internal RS-232

2 x USB 3.0

2 x USB 2.0

Option

iRIS

1 x iRIS-1010 slot

Power

Power consumption

12V@2.72A (Intel® Core? i5-4300U CPU with two 8 GB 1600 MHz DDR3 memory)

Storage

Storage

2 x SATA 6Gb/s with 5V power connector (RAID 0, 1)

System

CPU

» 5th generation Intel® mobile ULT on-board SoC

Intel® Core? i7-5650U (2.2GHz, dual-core, 4MB cache, TDP=15W)

Intel® Core? i5-5350U (1.8GHz, dual-core, 3MB cache, TDP=15W)

Intel® Core? i3-5010U (2.1GHz, dual-core, 3MB cache, TDP=15W)

Intel® Celeron® processor 3765U (1.9GHz, dual-core, 2MB cache, TDP=15W)

» 4th generation Intel® mobile ULT on-board SoC

Intel® Core? i7-4650U (1.7GHz, dual-core, 4MB cache, TDP=15W)

Intel® Core? i5-4300U (1.9GHz, dual-core, 3MB cache, TDP=15W)

Intel® Core? i3-4010U (1.7GHz, dual-core, 3MB cache, TDP=15W)

Intel® Celeron® processor 2980U (1.6GHz, dual-core, 2MB cache, TDP=15W)

Memory Max.

Two 204-pin 1600/1333 MHz dual-channel DDR3L SDRAM SO-DIMM slots support up to 16 GB

Watchdog Timer

Watchdog Timer

Software programmable, support 1~255 sec. system reset
