Spec Item

Description

CPU Cooler

CPU Cooler

Specific Heatsink

Display

Display

Dual display supported

1 x VGA Integrated in Intel® CPU

1 x Single-channel 18-bit

(N2600)/24-bit LVDS2 (D2550)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C with free air, -20°C ~ 70°C with force air for D2550 processor

-20°C ~ 70°C with free air, -20°C ~ 75°C with force air for N2600 processor

Expansion Slots

Expansion Slots

1 x Full/Half-size PCIe Mini card

slot with mSATA support

1 x PCI-104 slot supports PCI singal

I/O Interface

Audio

Realtek ALC662 HD Audio codec

Digital I/O

8-bit digital I/O (4-bit input / 4-bit output)

Ethernet

Dual LAN: Realtek RTL8111E controllers

I/O Interface

5 x RS-232

1 x RS-422/485

4 x USB2.0

1 x 6-pin wafer for PS/2 KB/MS

I/O Interface

I/O Interface

2 x USB 2.0

2 x Internal USB 2.0

5 x RS-232

1 x RS-422/485

Power

Power consumption

12V@1.19A (1.86GHz Intel® D2550 with on-board 1066MHz 1GB SDRAM)

12V@0.95A (1.6GHz Intel® N2600 with on-board 1066MHz 1GB SDRAM)

Storage

Storage

2 x SATA 3Gb/s or

1 x SATA 3Gb/s + 1 x mSATA

System

Chipset

Intel® NM10

CPU

Intel® Atom? D2550 (1.86GHz, dual-core, 1MB cache)

Intel® Atom? N2600 (1.6GHz, dual-core, 1MB cache)

Intel® Atom? N2800 (1.86GHz, dual-core, 1MB cache)

CPU Socket

On board

Memory Max.

On-board DDR3 1066MHz 2GB SDRAM

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
