Spec Item

Description

Dimensions

Dimensions

146mm x 102mm

Display

Display Output

Triple independent display

2 x HDMI (up to 3840x2160@30Hz)

1 x 18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz)

Environment

Operating Temperature

-20°C ~ 60°C

Humidity

5% ~ 95%, non-condensing

Expansion Slots

Expansion Slots

2 x Full/Half-size PCIe Mini card slot (1 w/ SIM holder) (1 w/ mSATA support: share SATA signal from SATA2)

I/O Interface

Ethernet

LAN1: Realtek RTL8111GN controller

LAN2: Realtek RTL8111GN controller

Digital I/O

1 x 8-bit digital I/O (1x10 pin, P=1.25)

Audio

Realtek ALC662 HD codec 1 x Analog audio (2x5 pin)

Other On-board Devices and Interfaces

1 x eMMC4.51 (optional)

I/O Interface

1x I²C((1 x 4 pin))

1 x SMBus((1 x 4 pin))

2 x SATA 6Gb/s(with 5V SATA power connector (no RAID))

3 x Internal RS-232((1 x 9 pin, P=1.25))

4 x Internal USB 2.0((2 x 4 pin, P=2.0))

2 x Internal RS-232/422/485(2 by pin header; 1x9 pin, P=1.25)

SMBus((1 x 4 pin))

1 x KB/MS((1 x 6 pin))

I/O Interface

1

Power

Power consumption

12V@1.52A (Intel® Pentium® processor N3710 with 8 GB 1600 MHz DDR3L memory)

Power Supply

12V only DC input

1 x Internal power connector (2x2 pin)

Support AT/ATX mode

System

CPU

Intel® Pentium® N3710 on-board SoC (up to 2.56GHz, quad-core, 2MB cache, TDP=6W)

Intel® Celeron® N3160 on-board SoC (up to 2.24GHz, quad-core, 2MB cache, TDP=6W)

Intel® Celeron® N3060 on-board SoC (up to 2.48GHz, dual-core, 2MB cache, TDP=6W)

Intel® Celeron® N3010 on-board SoC (up to 2.24GHz, dual-core, 2MB cache, TDP=4W)

Memory Max.

One 204-pin 1333/1600 MHz single-channel DDR3L SDRAM unbuffered SO-DIMM slot supports up to 8 GB

Weight

Weight

GW:600g, NW: 250g
