Spec Item |
Description |
CPU Cooler |
|
CPU Cooler |
N/A |
Display |
|
Display |
Triple independent display |
2 x HDMI (up to 4096x2160@24Hz) |
|
1 x 18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz) |
|
Environment |
|
Humidity |
5% ~ 95%, non-condensing |
Operating Temperature |
-20°C ~ 60°C |
Expansion Slots |
|
Expansion Slots |
1 x Full-size PCIe Mini card slot (with SIM holder & mSATA support) |
1 x Half-size PCIe Mini card slot |
|
I/O Interface |
|
Audio |
Realtek ALC662 HD codec 1 x Analog audio (2x5 pin) |
Digital I/O |
1 x 8-bit digital I/O (2x5 pin) |
Ethernet |
LAN1: Intel® I219-LM PHY with Intel® AMT 11.0 supported |
LAN2: Intel® I211-AT PCIe GbE controller |
|
I/O Interface |
|
I/O Interface |
4 x USB 3.0 |
3 x Internal USB 2.0 |
|
Power |
|
Power consumption |
12V@2.48A (Intel® Core? i3-6100U CPU with two 8 GB memory) |
Storage |
|
Storage |
1 x 8 GB eMMC (optional) |
2 x SATA 6G/s with 5V SATA power connector (RAID 0,1) |
|
System |
|
CPU |
6th generation Intel® mobile ULT on-board SoC |
Intel® Core? i7-6600U (up to 3.4GHz, dual-core, 4MB cache, TDP=15W) |
|
Intel® Core? i5-6300U (up to 3.0GHz, dual-core, 3MB cache, TDP=15W) |
|
Intel® Core? i3-6100U (up to 2.3GHz, dual-core, 3MB cache, TDP=15W) |
|
Intel® Celeron® processor 3955U (up to 2.0GHz, dual-core, 2MB cache, TDP=15W) |
|
Memory Max. |
Two 260-pin 2133/1866 MHz dual-channel DDR4 non-ECC unbuffered SO-DIMMs (system max. |
32 GB) |
|
Watchdog Timer |
|
Watchdog Timer |
Software programmable supports 1~255 sec. system reset |
