Spec Item

Description

CPU Cooler

CPU Cooler

CF-479B-RS / CF-989B-RS

Display

Display

Dual display supported

1 x VGA

2 x HDMI

1 x 18/24-bit dual-channel LVDS

Environment

Humidity

5% ~ 95% non-condensing

Operating Temperature

-10°C ~ 60°C (14°F ~ 140°F)

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot with mSATA support

I/O Interface

Audio

Realtek ALC662 HD Audio codec

Digital I/O

8-bit digital I/O (4-bit input / 4-bit output)

Ethernet

LAN1: Intel® I218LM PHY with Intel® AMT 9.0 supported

LAN2: Intel® I211AT PCIe GbE controller

I/O Interface

4 x USB 2.0

2 x USB 3.0

2 x RS-232

1 x RS-422/485

1 x PS/2 KB/MS

I/O Interface

I/O Interface

4 x USB 2.0

1 x RS-422/485

2 x RS-232

2 x USB 3.0

Option

iRIS

1 x iRIS-1010 slot

Power

Power consumption

12V@3.78A (Intel® 4th Gen. 2.0GHz CPU with one 1333HMz DDR3 4GB memory)

Storage

Storage

2 x SATA

System

Chipset

Intel® QM87

CPU

Intel® Core? i7/i5/i3, Celeron® Mobile processor

CPU Socket

On board

Memory Max.

1 x 204-pin 1600/1333MHz dualchannel DDR3/DDR3L SO-DIMM (system max. 8GB)

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
