Spec Item

Description

CPU Cooler

CPU Cooler

Heat Spreader

Display

Display

Dual display supported

VGA (up to 1920x1200@60Hz)

(Due to Intel GMA driver limitation, the monitor connected to the VGA connector may not have signal to it or become extended desktop after restarting from the graphics driver installation. To solve this problem, press the Ctrl+Alt+F1 hotkey to switch the primary screen to CRT mode.)

HDMI (up to 1920x1200@60Hz)

24-bit single-channel LVDS1 (D2550)

(up to 1440x900@60Hz)

18-bit single-channel LVDS1 (N2600/N2800)

(up to 1366x768@60Hz)

24-bit dual-channel LVDS2 (up to 1920x1200@60Hz)

DP to LVDS converter (up to 1920x1200(D2550) or 1600x1200(N2600/N2800)@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C with free air, -20°C ~ 70°C with force air for D2550 processor

-20°C ~ 70°C with free air, -20°C ~ 75°C with force air for N2600 processor

Expansion Slots

Expansion Slots

1 x PCIe Mini card slot with

mSATA support

1 x half-size PCIe Mini card slot

I/O Interface

Audio

Realtek ALC662 HD Audio Codec

Digital I/O

8-bit digital I/O (4-bit input / 4-bit output)

Ethernet

Dual Realtek RTL8111E PCIe GbE controllers with ASF 2.0 support

I/O Interface

3 x RS-232

1 x RS-422/485

6 x USB 2.0

1 x 6-pin header for KB/MS

I/O Interface

I/O Interface

1 x RS-422/485

6 x USB 2.0

3 x RS-232

Power

Power consumption

12V@1.59A (Intel® dual core D2550 CPU with 1333MHz 4GB DDR3 memory)

12V@1.23A (Intel® dual core N2600 CPU with 1333MHz 4GB DDR3 memory)

Storage

Storage

2 x SATA 3Gb/s or

1 x SATA 3Gb/s + 1 x mSATA

System

Chipset

Intel® NM10

CPU

Intel® Atom? D2550 1.86GHz

Intel® Atom? N2600 1.6GHz

CPU Socket

On Board

Memory Max.

1 x 204-pin 1066 MHz 4 GB DDR3 SO-DIMM (system max. 4GB) for D2550

1 x 204-pin 800 MHz 2 GB DDR3 SO-DIMM (system max. 2GB) for N2600

Watchdog Timer

Watchdog Timer

Software programmable and supports 1~255 sec. system reset
