Spec Item

Description

CPU Cooler

CPU Cooler

N/A

Display

Display

Dual independent display

VGA (up to 2560x1600 @ 60 Hz)

HDMI (up to 1920x1080 @ 60 Hz)

18/24-bit dual-channel LVDS by CH7511B DP to LVDS converter (up to 1920x1200@60Hz)

Environment

Humidity

10% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C (NANO-BT-i1-XXXXXX-R11)

-40°C ~ 85°C (NANO-BT-E38XX1W2-R11)

Expansion Slots

Expansion Slots

1 x Full-size PCIe Mini card slot (support mSATA co-lay SATA port 2)

1 x PCI/104 slot (PCI signal)

1 x microSD slot (E38XX SKU only)

I/O Interface

Audio

Realtek ALC662 HD Audio codec

1 x Analog audio (2x5 pin)

Digital I/O

1 x 8-bit digital I/O (2x5 pin)

Ethernet

LAN1: Intel® I210-AT PCIe controller with NCSI support

LAN2: Intel® I211-AT PCIe controller

I/O Interface

I/O Interface

1 x USB 3.0

1 x USB 2.0

1 x Internal RS-422/485

2 x Internal USB 2.0

3 x Internal RS-232

Option

iRIS

1 x iRIS-1010 slot

Power

Power consumption

12V@1.52A (Intel® Atom? processor J1900 with one 8GB 1333 MHz DDR3 memory)

Storage

Storage

2 x SATA 3Gb/s with 5V SATA power connector (no RAID)

System

CPU

Intel® Atom? E3845 on-board SoC (1.91GHz, quad-core, 2MB cache, TDP=10W)

CPU Socket

On Board

Memory Max.

One 204-pin 1066/1333MHz single-channel unbuffered DDR3L SDRAM SO-DIMM supports

up to 8 GB (J1900, N2930, E3845, E3827, E3826) or 4 GB (N2807, E3825, E3815)

Watchdog Timer

Watchdog Timer

Software programmable, support 1~255 sec. system reset
