Spec Item

Description

Display

Display

DVI-I (DVI-D up to 1920x1200@60Hz, VGA up to 2048x1536@60Hz)

18-bit single-channel LVDS (up to 1600x900@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

0°C ~ 60°C

I/O Interface

Audio

Realtek AL662 HD Audio codec

1 x Analog audio (2x5 pin)

Ethernet

LAN: Realtek RTL8111E controllers with ASF2.0 supported

I/O Interface

I/O Interface

2 x USB 3.0

1 x Internal RS-232

2 x Internal USB 2.0

Power

Power consumption

+12V@1.45A (AMD GX-415GA 1.5GHz CPU with one 2GB 1333 MHz DDR3 memory)

System

CPU

GX-415GA on-board SoC (1.5GHz, quad-core, 2MB cache, TDP=15W)

GX-210HA on-board SoC (1.0GHz, dual-core, 1MB cache, TDP=9W) (support fanless solution)

GX-420CA on-board SoC (2.0GHz, quad-core, 2MB cache, TDP=25W)

GX-217GA on-board SoC (1.65GHz, dual-core, 1MB cache, TDP=15W)

CPU Socket

On Board

Memory Max.

One 204-pin 1600/1333 MHz dual-channel DDR3 & DDR3L SDRAM unbuffered DIMM supports up to 8GB

Storage

1 x SATA 6Gb/s with 5V SATA power connector

Watchdog Timer

Watchdog Timer

Software programmable, support 1~255 sec. system reset
