Spec Item

Description

Display

Display Output

Dual independent display

1 x VGA (up to 2560x1600@60Hz)

1 x iDP interface for HDMI, LVDS, VGA, DVI, DP (up to 2560x1600@60Hz)

Environment

Humidity

5% ~ 95%, non-condensing

Operating Temperature

-20°C ~ 60°C

I/O Interface

Audio

Realtek ALC662 HD codec supports 5.1-channel

Ethernet

Intel® I211-AT PCIe controller

I/O Interface

I/O Interface

1 x USB 3.0

1 x Internal RS-232

2 x Internal USB 2.0

1 x USB 2.0

Power

Power consumption

+12V@1.35A (Intel® Celeron® J1900 with one 4GB 1333 MHz DDR3 memory)

SoC

SoC

Intel® Atom? E3845 on-board SoC (1.91GHz, quad-core, 2MB cache, TDP=10W)

Intel® Atom? E3827 on-board SoC (1.75GHz, dual-core, 1MB cache, TDP=8W)

Intel® Atom? E3826 on-board SoC (1.46GHz, dual-core, 1MB cache, TDP=7W)

Intel® Atom? E3825 on-board SoC (1.33GHz, dual-core, 1MB cache, TDP=6W)

Intel® Atom? E3815 on-board SoC (1.46GHz, dual-core, 1MB cache, TDP=5W)

Intel® Celeron® J1900 on-board SoC (2GHz, quad-core, 2MB cache, TDP=10W)

Intel® Celeron® N2930 on-board SoC (1.83GHz, quad-core, 2MB cache, TDP=7.5W)

Intel® Celeron® N2807 on-board SoC (1.58GHz, dual-core, 2MB cache, TDP=4.3W)

Storage

Storage

1 x SATA 3Gb/s with 5V SATA power connector

System

Memory Max.

One 204-pin 1066/1333 MHz single-channel DDR3L SO-DIMM supports up to 8GB (J1900, N2930, E3845, E3827, E3826) or 4GB (N2807, E3825, E3815)

Watchdog Timer

Watchdog Timer

Software programmable, support 1~255 sec. system reset
