Spec Item

Description

System

CPU

Intel® Mobile Core? i7/i5/i3/Celeron® CPU

Chipset

Intel® HM65

Memory Max.

Two 204-pin 1333/1066 MHz dual-channel DDR3 SO-DIMMs supported (system max.16GB)

CPU Socket

Socket 988B

I/O Interface

Ethernet

LAN1: Realtek RTL8111E GbE controller with ASF 2.0 support

LAN2: Realtek RTL8111E GbE controller

Digital I/O

8-bit digital I/O (4-bit input, 4-bit output)

Display

Dual display supported

1 x VGA (up to 2048 x 1536 @75Hz)

1 x 18/24-bit dual-channel LVDS (up to 1920 x 1200 @60Hz)

Audio

Supports 7.1 channel HD audio by IEI AC-KIT-892HD-R10 kit

I/O Interface

I/O Interface

2 x Internal RS-232

1 x Internal RS-422/485

6 x Internal USB 2.0

1 x KB/MS

1 x LPT

2 x USB 2.0

Power

Power consumption

5V@3.99A, 12V@0.43A, Vcore_12V@3.80A, 5VSB@0.06A (2.70GHz Intel® Core? i7-2620M with two 2GB 1333MHz DDR3 memory)

Environment

Operating Temperature

-10°C ~ 60°C

Humidity

10% ~ 95%, non-condensing

Storage

Storage

1 x SATA 3Gb/s

1 x SATA 6Gb/s

Expansion Slots

Expansion Slots

PCIe signal and PCI signal via golden finger

Watchdog Timer

Watchdog Timer

Software programmable supports 1~255 sec. system reset
